5000L 4-Layer Large High-Precision Water Tank Blow Molding Machine with Efficient
| Herkunftsort | CHINA |
|---|---|
| Markenname | HUAYU |
| Zertifizierung | ISO9001 CE |
| Modellnummer | HYBM5000-4 |
| Min Bestellmenge | 1 Set |
| Preis | 460000 USD |
| Verpackung Informationen | für den Containertransport in viele Teile zerlegt werden |
| Lieferzeit | 4 Monate |
| Zahlungsbedingungen | T/t, l/c |
| Versorgungsmaterial-Fähigkeit | 1 Satz 120 Tage |
Kontaktieren Sie mich für kostenlose Proben und Gutscheine.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
Wenn Sie Bedenken haben, bieten wir 24-Stunden-Online-Hilfe.
xProduktdetails
| Wasserverbrauch abkühlen | 60m3/h | Klemmkraft | 2500 kn |
|---|---|---|---|
| Automatisch | Ja | Fütterungsmotor | 2.2kw*8 |
| Kühlsystem | Wasserkühlung | Stromspannung | Kundenspezifisch |
| Produktmaterial | HDPE | Stromversorgung | 380 V/50 Hz |
| Jahr | 2024 | Schichten | 4 Schichten |
| Parison | MOOG 200 Punkte | After Sales | Übersee -Service |
| Gesamtgewicht | 50t | Verfügbare Produktion | Wasserbehälter, anderes Kunststoffprodukt |
| Luftversorgung | 0.8*6 ((Mpa*Kubikmeter pro Minute) | ||
| Hervorheben | 5000L water tank blow molding machine,4-layer high-precision blow molding machine,large water tank molding machine with warranty |
||
Sie können die gewünschten Produkte ankreuzen und im Message Board mit uns kommunizieren.
Produkt-Beschreibung
This high-precision blow molding machine with a 5000L capacity and 4-layer co-extrusion is designed for producing high-quality, multi-layered plastic products. The integrated water tank system ensures accurate temperature control and consistent cooling, resulting in superior product quality. The machine's advanced control system offers precise control over the molding process, ensuring consistent product dimensions and quality. Its durable construction and reliable performance make it suitable for industries requiring high-precision plastic products. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.
|
blowing and cooling system |
||
|
stretching stroke |
according to products |
|
|
blow pin up/down stroke |
600mm |
|
|
air seat stroke |
400mm |
|
|
maximum air pressure |
0.8Mpa |
|
|
air consumption |
3m3/min |
|
|
Cooling method |
Circulating water |
|
|
Water pressure |
0.3MPa |
|
|
ling water consumption |
75m3/h |
|
|
Hydraulic system |
||
|
main oil tank capacity |
1500L |
Servo motor, less energy consumption, high efficiency, low noise |
|
main oil pump |
gear pump185CC |
|
|
main oil pump motor |
60kw |
|
|
Servo oil tank capacity |
200L |
|
|
Servo oil pump model |
Plunger pump35 |
|
|
Servo oil pump motor |
11kw |
|
